processor

Xeon E5 LGA1356 Pin Series Processor

Southbridge

HM70 Chipset series

memory

technology

Dual-channel DDR3 1066/1333/1600/1866MHz

maximum capacity

64GB

Memory slot

2 * 240 PIN DDR3

Post I/O

USB port

6 USB 2.0

Ethernet

1 Realtek Gigabit NIC

Audio

1 (Mic-in, Line-out, Line-in)

Internal connector

USB 2.0

2 (one FUSB can switch out two USB 2.0 interfaces);

serial ata

4 SATA ports (3 SATA2.0,1 and 1 SATA3.0)

PCIe

2 (1 PCIe x16；; 1 PCIe x1)

ATXPWR interface

1 standard 1x8PIN power socket; 1 standard 1x24PIN power socket

Audio

1 x 2x5Pin pin

M.2 interface

1 M.2 interface

Physical size

measure

171 mm x 216 mm
